{"Category":"Discrete Semiconductor Products","Operating Temperature - Junction":"-65\u00b0C ~ 175\u00b0C","Catalog Drawings":"Power Diode Circuit","Package / Case":"TO-247-2","Product Photos":"TO-247-2-Series","PCN Assembly/Origin":"Assembly Site Transfer 06/Apr/2015","PCN Design/Specification":"Plating Material 20/Dec/2007","Reverse Recovery Time (trr)":"50ns","Datasheets":"RHRG5060","Standard Package":"30","Current - Average Rectified (Io)":"50A","Voltage - Forward (Vf) (Max) @ If":"2.1V @ 50A","Voltage ...

{"Category":"Discrete Semiconductor Products","Packaging":"Tube","Current - Reverse Leakage @ Vr":"250\u00b5A @ 600V","Product Photos":"TO-247-2-Series","Family":"Diodes, Rectifiers - Single","Standard Package":"30","Series":"-","Capacitance @ Vr, F":"-","Voltage - Forward (Vf) (Max) @ If":"2.1V @ 50A","Supplier Device Package":"TO-247","Reverse Recovery Time (trr)":"60ns","Datasheets":"RHRG5060_F085","Current - Average Rectified (Io)":"50A","Operating Temperature - Junction":"-55\u00b0C ~ 175\u00b0C","Pack...

{"I(FSM) Max.(A) Pk.Fwd.Sur.Cur.":"500","I(O) Max.(A) Output Current":"50","@t(w) (s) (Test Condition)":"8.3m","V(FM) Max.(V) Forward Voltage":"2.1","Status":"Discontinued","@Temp. (°C) (Test Condition)":"150","@V(R) (V)(Test Condition)":"400","V(RRM)(V) Rep.Pk.Rev. Voltage":"400","t(rr) Max.(s) Rev.Rec. Time":"45n","Package":"TO-247var","I(RM) Max.(A) Pk. Rev. Current":"1.5m","@I(F) (A) (Test Condition)":"1.0","Military":"N","Semiconductor Material":"Silicon","@Temp (°C) (Test Condition)":"93","I...

{"I(FSM) Max.(A) Pk.Fwd.Sur.Cur.":"500","I(O) Max.(A) Output Current":"50","@t(w) (s) (Test Condition)":"8.3m","V(FM) Max.(V) Forward Voltage":"2.1","Status":"Discontinued","@Temp. (°C) (Test Condition)":"150","@V(R) (V)(Test Condition)":"500","V(RRM)(V) Rep.Pk.Rev. Voltage":"500","t(rr) Max.(s) Rev.Rec. Time":"45n","Package":"TO-247var","I(RM) Max.(A) Pk. Rev. Current":"1.5m","@I(F) (A) (Test Condition)":"1.0","Military":"N","Semiconductor Material":"Silicon","@Temp (°C) (Test Condition)":"93","I...

{"I(FSM) Max.(A) Pk.Fwd.Sur.Cur.":"100","I(O) Max.(A) Output Current":"50","@t(w) (s) (Test Condition)":"25u","V(FM) Max.(V) Forward Voltage":"3.0","Status":"Discontinued","@Temp. (°C) (Test Condition)":"150","@V(R) (V)(Test Condition)":"700","V(RRM)(V) Rep.Pk.Rev. Voltage":"700","t(rr) Max.(s) Rev.Rec. Time":"75n","Package":"TO-247","I(RM) Max.(A) Pk. Rev. Current":"3.0m","@I(F) (A) (Test Condition)":"1","Military":"N","Semiconductor Material":"Silicon","@Temp (°C) (Test Condition)":"25","I(RM) M...

{"I(FSM) Max.(A) Pk.Fwd.Sur.Cur.":"100","I(O) Max.(A) Output Current":"50","@t(w) (s) (Test Condition)":"25u","V(FM) Max.(V) Forward Voltage":"3.0","Status":"Discontinued","@Temp. (°C) (Test Condition)":"150","@V(R) (V)(Test Condition)":"800","V(RRM)(V) Rep.Pk.Rev. Voltage":"800","t(rr) Max.(s) Rev.Rec. Time":"75n","Package":"TO-247","I(RM) Max.(A) Pk. Rev. Current":"3.0m","@I(F) (A) (Test Condition)":"1","Military":"N","Semiconductor Material":"Silicon","@Temp (°C) (Test Condition)":"25","I(RM) M...

{"I(FSM) Max.(A) Pk.Fwd.Sur.Cur.":"100","I(O) Max.(A) Output Current":"50","@t(w) (s) (Test Condition)":"25u","V(FM) Max.(V) Forward Voltage":"3.0","Status":"Discontinued","@Temp. (°C) (Test Condition)":"150","@V(R) (V)(Test Condition)":"900","V(RRM)(V) Rep.Pk.Rev. Voltage":"900","t(rr) Max.(s) Rev.Rec. Time":"75n","Package":"TO-247","I(RM) Max.(A) Pk. Rev. Current":"3.0m","@I(F) (A) (Test Condition)":"1","Military":"N","Semiconductor Material":"Silicon","@Temp (°C) (Test Condition)":"25","I(RM) M...

{"Peak Rep Rev Volt":"600(V)","Product Depth (mm)":"4.7(mm)","Peak Non-Repetitive Surge Current":"500(A)","Rectifier Type":"Switching Diode","Peak Reverse Recovery Time":"50(ns)","Mounting":"Through Hole","Forward Current":"50000(mA)","Peak Reverse Current":"250(uA)","Forward Voltage":"2.1(V)","Packaging":"Rail/Tube","Operating Temperature Classification":"Military","Rad Hardened":"No","Rev Recov Time":"50(ns)","Package Type":"TO-247","Operating Temp Range":"-65C to 175C","Maximum Forward Current":"50000(mA...

{"Rectifier Type":"Switching Diode","Peak Rep Rev Volt":"600(V)","Peak Non-Repetitive Surge Current":"150(A)","Forward Current":"50000(mA)","Mounting":"Through Hole","Rad Hardened":"No","Forward Voltage":"2.1(V)","Packaging":"Rail/Tube","Operating Temperature Classification":"Military","Operating Temp Range":"-55C to 175C","Rev Recov Time":"60(ns)","Package Type":"TO-247","Rev Curr":"250(uA)","Configuration":"Single","Pin Count":"2 +Tab"}...

{"Peak Rep Rev Volt":"600(V)","Rev Curr":"250(uA)","Peak Non-Repetitive Surge Current":"150(A)","Rectifier Type":"Switching Diode","Peak Reverse Recovery Time":"60(ns)","Mounting":"Through Hole","Forward Current":"50000(mA)","Forward Voltage":"2.1(V)","Product Depth (mm)":"4.7(mm)","Packaging":"Rail/Tube","Operating Temperature Classification":"Military","Rad Hardened":"No","Rev Recov Time":"60(ns)","Package Type":"TO-247","Peak Forward Voltage":"2.1(V)","Maximum Forward Current":"50000(mA)","Operating Temp...
