{"Category":"Discrete Semiconductor Products","Voltage - Off State":"1400V","Voltage - Gate Trigger (Vgt) (Max)":"1.5V","Operating Temperature":"-40\u00b0C ~ 125\u00b0C","Package / Case":"TO-208AC, TO-65-3, Stud","Current - Hold (Ih) (Max)":"80mA","Product Photos":"TO-65","Current - On State (It (RMS)) (Max)":"120A","Current - Non Rep. Surge 50, 60Hz (Itsm)":"1200A, 1340A","Datasheets":"CS35","Standard Package":"10","Current - Off State (Max)":"10mA","Current - Gate Trigger (Igt) (Max)":"100mA","Voltage - O...

{"Peak Non Rep Surge Current Itsm 50Hz:":"1.2 kA","Peak Repetitive Off-State Voltage, Vdrm:":"1.4 kV","Gate Trigger Current Max, Igt:":"100 mA","Current It av:":"69 A","MSL:":"-","No. of Pins:":"3","Gate Trigger Voltage Max Vgt:":"1.5 V","Thyristor Case Style:":"TO-208AC","Operating Temperature Max:":"125 \u00b0C","Holding Current Max Ih:":"80 mA","On State RMS Current IT(rms):":"120 A","SVHC:":"No SVHC (17-Dec-2014)"}...

{"Status":"ACTIVE","Lead Free":"Yes","Terminal Finish":"PURE TIN","Package Body Material":"METAL","Mfr Package Description":"TO-65, 2 PIN","Repetitive Peak Off-state Voltage":"1400 V","Terminal Form":"UNSPECIFIED","Package Style":"POST/STUD MOUNT","RMS On-state Current-Max":"120 A","Repetitive Peak Reverse Voltage":"1400 V","DC Gate Trigger Current-Max":"100 mA","Case Connection":"ANODE","Trigger Device Type":"SCR","EU RoHS Compliant":"Yes","Terminal Position":"UPPER","Package Shape":"ROUND","Configuration"...
